Specification
AudioOutputMode : Stereo
Brand : AOSHIDA
BulletPoint1 : Dual ES9039SPRO Chips: The core of D90 III SABRE is driven by two ES9039SPRO chips, each audio channel operates independently, which provides a higher signal-to-noise ratio of 135dB, greater dynamic range and significantly reduced distortion <0.000045% THD+N.
BulletPoint2 : Advanced CPLD Processing: D90III Sabre uses CPLD to process clock signals and optimize digital signals for incredible jitter suppression. Regardless of USB, optical, coaxial, AES input, jItter is as low as -160dB.
BulletPoint3 : New I/V conversion circuit: A new I/V conversion circuit built into the D90 III SABRE enables better audio reproduction quality. This circuit design provides lower distortion and lower noise while taking up less space.
BulletPoint4 : IIS interface: DAC IIS needs to match the IIS interface definition of the digital interface. The D90 III SABRE supports II mode selection: DSD FLAG 15, DSD FLAG 14, IIS DSDR LRCLK, IIS DSDR DATA, IIS PHASE STD, IIS PHASE REV. It is compatible with most digital interfaces.
BulletPoint5 : QCC5125 Bluetooth 5.1 LDAC: D90III SABRE is equipped with QCC5125 and Bluetooth 5. 1, supports LDAC/aptX-Adaptive/aptX- HD/AAC/SBC . It can support up to 96kHz/24bit, so that high-quality audio can be transmitted wireless to obtain music experience beyond CD level.
BulletPoint6 : Preamplifier function: In addition to the fixed output level DAC mode, the D90III SABRE also has a "preamp" mode. In this mode, the D90III SABRE can adjust the volume and output directly to the power amplifier or active speakers.
Color : Black
CompatibleDevices : Speaker
ConnectivityTechnology : ['USB', 'RCA']
ConnectorType : ['USB', 'RCA']
ControllerType : Windows 7
ControlMethod : remote
IncludedComponents : Remote Controller
IncludedComponents1 : 1*U5 Headphone Amplifier
IncludedComponents2 : 1*USB to DC Cable
InterfaceType : USB, Coaxial, Optical, RCA, AES
ItemName : Topping D90III Sabre MQA-CD Full Balanced DAC Preamp with Dual ES9039SPRO, USB/Bluetooth/Optic/Coaxial/AES/IIS Input RCA/XLR Output Digital-Analog Audio Converter Desktop MQA Decoder (Black)
ItemPackageDimensions_Height : 36.9 centimeters
ItemPackageDimensions_Length : 8.7 centimeters
ItemPackageDimensions_Width : 24.9 centimeters
ItemTypeKeyword : audio-component-amplifiers
Manufacturer : TOPPING
ModelNumber : D90 III Sabre
MountingType : Rack Mount
NumberOfBoxes : 1
NumberOfChannels : 4
NumberOfItems : 1
NumberOfPins : 50
PackageLevel : unit
PartNumber : D90III SABRE
ProductDescription : TOPPING D90III SABRE Full Balanced 2* ES9039SPRO USB/BT5.1/Optic/Coaxial/AES/IIS DA Converter MQA DAC

Product highlights
* Dual ES9039SPRO chips for superior audio quality
* Advanced CPLD processing for minimal jitter
* Innovative I/V conversion circuit for clarity
* Authentic sound reproduction with ultra-low THD+N
* High-resolution wireless audio with Bluetooth 5.1
* Versatile output modes with XLR and RCA options

D90 III SABRE DAC parameters (LineOut/USB In@96kHz)
THD+N (A-wt)
RCA: <0.00006% @1kHz
XLR: <0.000045% @1kHz

THD @90kBw (No-wt)
RCA: <0.0003% @20-20kHz
XLR: <0.0001%@20-20kHZ

SNR (A-wt)
RCA: 129dB @1kHz
XLR: 135dB @1kHz

Dynamic Range (A-wt)
RCA: 129dB @1kHz
XLR: 135dB @1kHz

Frequency Response
RCA: 20Hz-20kHz (±0.1dB), 20Hz-40kHz (±0.3dB)
XLR: 20Hz-20kHz (±0.1dB), 20Hz-40kHz (±0.3dB)

Output Level
RCA: 2.1Vrms @0dBFS (4V Mode), 2.6Vrms @0dBFS (5V Mode)
XLR: 4.2Vrms @0dBFS (4V Mode), 5.2Vrms @0dBF S (5V Mode)

Noise (A-wt)
RCA: <1.1uVrms
XLR: <1.1uVrms

Channel Crosstalk
RCA: - 133dB @ 1kHz
XLR: -149dB @1kHz

Channel Balance
RCA: 0.3dB
XLR: 0.3dB

Output Impedance
RCA: 50Ω
XLR: 100Ω
The size of the machine itself: Size: 22.2CM x 16.0CM x 4.5CM; Weight: 1.17Kg
Size after product packaging: Size: 37CM * 24CM * 9CM; Weight: 2.4KG

Accessories:
1* Remote control
1* USB cable
1* AC cable
1* Bluetooth Antenna
1* Product Information Card
ProductSiteLaunchDate : 2023-12-22T07:04:01.541Z
Size : U5
SupplierDeclaredDgHzRegulation : not_applicable
SurroundSoundChannelConfiguration : 2.1 Channel
TotalHdmiPorts : 1
UnspscCode : 52161547
VideoEncoding : HEVC Main 10
WarrantyDescription : 12-Month Limited Warranty
Wattage : 0.5 watts
WirelessCommunicationTechnology : Bluetooth
