Specification
AgeRangeDescription : adult
Brand : Microlab
BulletPoint : The lightweight design allows easy attachment to a wall using the supplied bracket
Color : One Color
ExternallyAssignedProductIdentifier : 7364640101057
Impedance : 50 ohm
ItemName : MicroLab/RF Industries - DN-74FE - Tapper, 50, 4.3-10 Female Connector, 350 to 5850 MHz Frequency, 500W, 10 dB, (
ItemPackageDimensions_Height : 3 inches
ItemPackageDimensions_Length : 8 inches
ItemPackageDimensions_Width : 4 inches
ItemPackageQuantity : 1
ItemTypeKeyword : electronic-component-antennas
Manufacturer : MicroLab / RF Industries
ModelName : NOVKMJVZ
ModelNumber : NOVKMJVZ
NumberOfBoxes : 1
NumberOfItems : 1
PartNumber : DN-74FE
ProductDescription : The lightweight design allows easy attachment to a wall using the supplied bracket. Designed with only a few solder joints and an air dielectric, See DN-x4FN, and DN-x4FD series for similar Tappers with N, and 7/16 connectors. Microlab DN-x4FN series of tappers unevenly split high power cellular signals in fixed ratios from 1000:1 to 2:1 with minimal reflections or loss over the key wireless bands in the range 350 - 5, 850 MHz, (there is no coupling 1550 to 1650 MHz). The innovative asymmetric design ensures an excellent input VSWR and coupling flatness across the specified bands, even down to a 2:1 split. The DN74-FE is a 10dB tapper with 4.3-10 female terminations. Split ratios from 1000:1 to 2:1 Tetra, PMR, cellular, UMTS, Wi-Fi to 5, 930 Low specified PIM 500W avg power rating Minimal RF insertion loss RoHS compliant High reliability, IP6 SpecificationsFrequency: 350 - 5, 930 MHz Ratio: 10:1/10dB Main/branch split: -0.4/-10.5 Power: 500W avg., 3 kW peak VSWR: 1.2:1 for 700-2500 MHz 1.3:1 for 350-5930 MHz PIM: -161 dBc (2 tones at +43dBm) Connectors: 4.3-10 (f) trimetal Ingress protection: IP67 This listing is for Each.
ProductSiteLaunchDate : 2020-01-08T16:38:13.923Z
Size : Temp 2 in 2 out
UnitCount : 1
UnspscCode : 39121400
