Specification
BatteriesRequired : 1
Brand : Alinan
BulletPoint1 : ★Over Charge Voltage:4.25-4.35v±0.05v; Over Discharge Voltage: 2.3-3.0v±0.05v; Max Operating Current: 4-5A; Max Instantaneous Current: 10A.
BulletPoint2 : 【Multiple Protection】: Over-discharge protection, overcurrent protection, overcharge protection, short circuit protection.
BulletPoint3 : ★MOS transistor can control the battery charge and discharge, low standby current consumption.
BulletPoint4 : 【Applications】: Use for variety of capacities and various shapes 3.7V lithium batteries,Massager battery pack, LED light backup power supply, solar street light battery pack, monitor standby power supply, etc.
BulletPoint5 : 【Note】: B+: connected battery positive; B1: the connect point between battery 1 and battery 2; B2: connect the point between battery2 and battery 3; B3: Connect the point between battery 3 and battery; B-: connect to battery negative end; P+: connection charge/discharge positive; P-: connection charge/discharge negative.
Color : Green
ExternallyAssignedProductIdentifier1 : 0701715521438
ExternallyAssignedProductIdentifier2 : 701715521438
GpsrSafetyAttestation : 1
InputVoltage : 3.7 volts
ItemName : Alinan 6pcs 4S 14.4V 14.8V 16.8V 5A 18650 Lithium Battery Protection Board Overcharge Protection BMS PCB Circuit Module
ItemPackageDimensions_Height : 7.1882 centimeters
ItemPackageDimensions_Length : 0.7874 centimeters
ItemPackageDimensions_Width : 5.9944 centimeters
ItemTypeKeyword : automotive-battery-chargers
Manufacturer : Alinan
ModelNumber : 6pcs
NumberOfItems : 6
OutputVoltage : 16.8 volts_of_direct_current
ProductDescription : Feature:
Over Charge Voltage:4.25-4.35v±0.05v
Over Discharge Voltage: 2.3-3.0v±0.05v
Upper Limit Operating Current: 4-5A
Max Peak Current: 6-8A
Max Instantaneous Current: 12A
Working Temperature: -40~+50 Celsius
Storage Temperature:-40~+80 Celsius
Static Current: less than 6uA
Life Cycle: more than 50000hours
Resistance: less than 45mΩ
Charging Voltage: 16.8-17V
Short Circuit Protection: Can be protected, charge recovery required
Size: 67mm x 16mm x 1mm/ 2.64″ ×0.63″×0.04″(L x W x H)

Note:
B+: connected battery positive
B1: the connect point between battery 1 and battery 2
B2: connect the point between battery2 and battery 3
B3: Connect the point between battery 3 and battery
B-: connect to battery negative end
P+: connection charge/discharge positive
P-: connection charge/discharge negative.
Please make sure truely connect, otherwise it will cause damage to the chip.
ProductSiteLaunchDate : 2022-07-05T06:05:43.528Z
SupplierDeclaredDgHzRegulation : not_applicable
UnspscCode : 26111700
WarrantyDescription : others
