Specification
Brand : Thomas & Betts
BulletPoint1 : Unique construction of the female disconnect offers long-term dependability
BulletPoint2 : Brazed seam serrated barrel provides maximum tensile strength
BulletPoint3 : Nylon insulated
BulletPoint4 : Brass
BulletPoint5 : Electro tin plated
Color : Blue
ConnectorType : Pin
ExternallyAssignedProductIdentifier : 1000135371630
ExternallyAssignedProductIdentifier1 : 0617401473601
ExternallyAssignedProductIdentifier2 : 617401473601
IncludedComponents : Tool
ItemName : T&B Nylon Insulated w/Insulation Grip Disconnects RB2577F Blue 16-14 AWG Female .250 Width 90 Degree Fully Insulated - 100 pack
ItemPackageDimensions_Height : 3.3 inches
ItemPackageDimensions_Length : 6.3 inches
ItemPackageDimensions_Width : 4.69 inches
ItemPackageQuantity : 100
ItemTypeKeyword : disconnect-terminals
Manufacturer : Thomas & Betts
Material : Nylon
Material1 : Heat Shrink and Tin Plated Brass
Material2 : Heat Shrink and Tin Plated Brass
MeasurementSystem : Imperial
ModelNumber : RB2577F
NationalStockNumber : 5940-01-068-1879
NumberOfItems : 100
OperatingVoltage : 600 volts
PartNumber : RB2577F
ProductDescription : Overview:
Mini-Fit Jr. and Mini-Fit Plus Power Connectors deliver up to 9.0A and 13.0A respectively, while blind-mating and terminal position assurance options offer a versatile connector system for a wide range of applications

Item Specification: Receptacle and Plug Housing Mini Fit JR
Mini-Fit Jr. Receptacle and Plug Housing, Dual Row
Approval: UL 94 V-2,
Material Polyamide
Rated: 13 Amps
Pitch - Mating Interface .0165" (4.20mm)
Pitch - Termination Interface .0165" (4.20mm)
Temperature Range - Operating: -40°C to +105°C

Item Specification: Terminals Mini Fit JR
Crimp or Compression Style Terminals
Made out of Brass Metal Material
Tin Plating Mating
9.0A Current - Maximum per Contact
600V Voltage - Maximum
Wire Insulation Diameter1.30 - 3.10mm
Wire Size accepted (AWG)18-24

Glow Wire referenced Molex product is manufactured from material that has the following ratings, tested by independent agencies:
a) A Glow Wire Ignition Temperature (GWIT) of at least 775 deg C per IEC 60695-2- 13.
b) A Glow Wire Flammability Index (GWFI) above 850 deg C per IEC 60695-2-12.
This complies with the requirements set out in the International Standard IEC 60335-1 5th edition - household and similar electrical appliances - safety, section 30 Resistance to heat and fire.
The customers using this product must determine its suitability for use in their particular application through testing or other acceptable means as described in end-product glow- wire flammability test standard IEC 60695-2-11 and any applicable product end-use standard(s).
If it is determined during the customer’s evaluation of suitability that the performance does not match customer needs, please contact Molex.

ProductSiteLaunchDate : 2014-10-27T11:54:31.058Z
Size : 1.04-Inch Length by 0.29-Inch Width
SpecificationMet : UL
SpecificationMet1 : UL
SpecificationMet2 : CE
SpecificationMet3 : RoHS
SupplierDeclaredDgHzRegulation : not_applicable
TemperatureRating : 90 degree celsius
TerminalType : Screw Terminal
UnitCount : 50
UnspscCode : 39121400
Voltage : 600 volts
