Specification
Brand : SHIHUANI
BulletPoint1 : 【PREMIUM MATERIAL】The housing of this planetary gearbox is made of hard aluminum alloy, which can protect the internal parts well and ensure longer service life. It adopts multiple precision threads to fit your motor tightly and is not easy to loosen.
BulletPoint2 : 【PRECISE SPEED ADJUSTMENT】 It has a reduction ratio , so you can change your motor speed more easily.
BulletPoint3 : 【REMOVABLE OUTPUT SHAFT】It adopts an enlarged rectangular base, which increases the contact area with the plane to ensure its stability when working.
BulletPoint4 : 【LOW NOISE DESIGN】This planetary gearbox uses lubrication to reduce friction between parts. As a result, so it protects your hearing. This one-piece gearbox reducer is very easy to replace. You can easily replace a rusty or damaged gearbox on your motor with it .
BulletPoint5 : 【WIDE APPLICATION】This planetary gearbox is is a great solution for applications that require quick stops, have shock loads, and have little space. widely working on mill, lathe, bench, and bandsaw machines.
BulletPoint6 : Series:New Series
Color : Ratio 70
ExternallyAssignedProductIdentifier : 8239865921027
ItemName : Planetary Reducer Helical Gear Nema17 Planetary Gearbox 4 15 30:1 3 Arcmin 5 8mm Input Reducer for 42mm Stepper Motor 40mm Servo(Ratio 70,8mm Input)
ItemPackageDimensions_Height : 1 centimeters
ItemPackageDimensions_Length : 3 centimeters
ItemPackageDimensions_Width : 2 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : mechanical-gearboxes
Manufacturer : SHIHUANI
ModelName : SHIHUANI
ModelNumber : SHIHUANI
NumberOfItems : 1
PartNumber : SHIHUANI
ProductDescription : Reducer parameters:
Speed Ratio: 1Stage(L1): 4:1/ 5:1 / 7:1 / 9:1 / 10:12Stage (L2):20:1 / 25:1 / 35:1/ 40:1/ 50:1/ 70:1/ 100:1
Product type:Helical GearPlanetary reducer
Input size: 5mm / 8mm
Body length: 60.3 (L1) / 86mm (L2)
Backlash Precision:Less than 3 Arcmin (L1)/ Less than 5 Arcmin (L2)
Gear type:Helical Gear
Rated torque:
19Nm (4:1/ 20:1/ 40:1) ;17Nm(5:1/ 25:1/ 35:1)
14Nm (7:1 / 70:1) ; 11Nm (10:1 / 100:1)
Maximum torque: 2* Rated torque
Emergency braking torque: 3* Rated torque
Max radial force: 780N
Max axial force : 390N
Max input speed: 8000rpm
Rated input speed: 4000rpm
Transmission efficiency: More than 97% (L1)/ More than 94% (L2)
Noise: less than 56dB
Protection level: IP65
==========
Model Number : PLG042-4-5-22-43.8
Construction : gearbox
Type : Gear Motor
Efficiency : IE 1
Origin : Mainland China
ProductSiteLaunchDate : 2024-10-29T08:12:44.515Z
Size : 8mm input
UnitCount : 1
UnspscCode : 26101200
