Specification
Brand : MEAN MELL
BulletPoint1 : Three-Phase 340~550VAC wide range input (Dual phase operation possible)
BulletPoint10 : BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
BulletPoint2 : Width only 85.5mm
BulletPoint3 : Built-in active PFC function compliance to BS EN/EN61000-3-2
BulletPoint4 : High efficiency 93% and low power dissipation
BulletPoint5 : Protections: Short circuit / Overload / Over voltage / Over temperature
BulletPoint6 : Cooling by free air convection
BulletPoint7 : Built-in constant current limiting circuit
BulletPoint8 : Can be installed on DIlN rail TS-35/7.5 or 15
BulletPoint9 : UL508(industrial control equipment)approved
Color : KBPC5010
CurrentRating : 10 amps
ExternallyAssignedProductIdentifier : 4711287452579
IncludedComponents : NO
ItemName : Mean Well TDR-480-48 480W Three Phase Industrial DIN Rail with PFC Function TDR-480 48V 10A
ItemPackageQuantity : 1
ItemTypeKeyword : isolation-transformers
Manufacturer : MEAN MELL
Material : Copper
ModelNumber : TDR-480-48
NumberOfItems : 200
PartNumber : TDR-480-48
ProductDescription : TDR-480 is one economical slim 480W DIN rail power supply series,adapt to be installed on TS-35/7.5orTS-35/15 mounting rails. The body is designed 85.5mm in width, which allows space saving inside thecabinets.The entire series adopts the full range AC input from 3p 340VAC to 550VAC(DualPhaseoperation possible) and conforms to BSEN/EN61000-3-2, the norm the European Union regulates for harmoniccurrent. TDR-480 is designed with metal housing that enhances the unit's power dissipation. With workingefficiency up to 93 %, the entire series can operate at the ambient temperature between-20℃ and 70'℃cunder air convection.It is equipped with constant current mode for overload protection, fitting variousinductive or capacitive applications. The complete protection functions and relevant certificates for industrialcontrol apparatus (UL508,IEC 62368-1 CB approved by UL.) make TDR-480 a very competitive powersupply solution for industrial applications.
ProductSiteLaunchDate : 2024-03-26T02:00:44.912Z
SupplierDeclaredDgHzRegulation : not_applicable
Wattage : 480 watts
