Specification
AgeRangeDescription : adult
Brand : KACOME
BulletPoint1 : Rotation: Spindle motors provide high speed stable rotation.
BulletPoint2 : Machining: The accuracy of the spindle motor directly affects the accuracy of the machined workpiece
BulletPoint3 : Application: Adapt to a variety of application scenarios
BulletPoint4 : Features: all size light weight
BulletPoint5 : Installation: Simple installation easy operation
BulletPoint6 : Complete Accessories -- This drilling and milling machine has a full range of accessories, including the support base and the corresponding milling chuck, with Milling chuck set (R8-ER32 : 4-3/6-5/8-7/10-9/12-11/16-15/18-17/20-19).Other accessories are Axis X power feed *1 Grating ruler *1 Drill chuck *1 Drill chuck retaining pin *1 Bench clamp *1 Fork wrench *1 Drill chuck wrench *1 Oil can *1 Cross screwdriver *1 Straight screwdriver *1 Hexagon wrench *4 English manual *1
BulletPoint7 : Safe and User-Friendly -- Includes a forward/reverse switch and an emergency stop for secure operation. The handwheel scale is in millimeters, providing precise control.
Color : 380v
ExternallyAssignedProductIdentifier : 7624570094936
ExternallyAssignedProductIdentifier1 : 0198462080873
ExternallyAssignedProductIdentifier2 : 198462080873
ItemName : KACOME 3.7kw Metal Processing Spindle kit 800Hz Stainless Steel Copper Steel & Inverter & 150w Water Pump(400Hz-12000rpm,380v)
ItemPackageDimensions_Height : 1 centimeters
ItemPackageDimensions_Length : 3 centimeters
ItemPackageDimensions_Width : 2 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : power-milling-machines
Manufacturer : KACOME
MaximumRotationalSpeed : 2250 rpm
ModelName : KACOME
ModelNumber : KACOME
NumberOfBoxes : 1
NumberOfItems : 1
PartNumber : KACOME
ProductDescription : 1& 220vAC37kw metal processing spindle motor water cooling 800Hz 4 pole diameter 100mm
1 220v 37kw frequency converter 1000Hz
1 100mm spindle bracket
1 150w water pump
1 5m water pipe
1 ER20 chuck 4 6 8 10 12. 1/4. 1/8)
Dimensions: 100x289.5mm (center body diameter: 100mm x length: 273mm)
Speed ​​regulation method: Through the three-phase output frequency converter, adjust the frequency converter to change the spindle speed.
Cooling method: water cooling
Power: 3.7kW
Voltage: 220V/380V
Current: 17A/8A
Frequency: 800 Hz
Speed: 6000-24000 rpm
Number of poles: 4
Runout deviation: less than 0.01 mm
Diameter (mm): 100
Bearing type: 2×7005 TQP4&2×7003 TQ P4
4 ceramic ball bearings full angular contact bearings
Input voltage: 220V (+/-15)
Input frequency: 50/60Hz
Input phase number: 1 phase or 3 phases
Output voltage: 220VAC
Output frequency: 0-1000 Hz
Output current: 17A
Number of output phases: three phases
Control mode V/F control mode
8-level simple PLC, multi-level speed control and PID control.
=========
Certification: CE
ProductSiteLaunchDate : 2024-10-30T02:20:31.351Z
Size : 400Hz-12000rpm
UnitCount : 1
UnspscCode : 52140000
Voltage : 110 volts
Wattage : 1300 watts
