Specification
Brand : Walfront
BulletPoint1 : [MULTIFUNCTIONAL TESTING] This 3-in-1 device combines a digital oscilloscope, component tester, and PWM generator for comprehensive electronic testing.
BulletPoint2 : [ADVANCED FUNCTIONS] Identify various transistors, measure waveforms, or test capacitance, , and inductance components with ease. for both professionals and hobbyists.
BulletPoint3 : [MULTIPLE COMPATIBILITY] Compatible with computer online work, rapid transistor pairing, and mixed component recognition, making testing efficient and convenient.
BulletPoint4 : [HIGH PERFORMANCE] Features a real-time sampling rate of 48MSa/s, 10MHz bandwidth, and a built-in 1500mAh battery for extended use. The 2.8-inch high-resolution screen provides clear readings.
BulletPoint5 : [PORTABLE DESIGN] Compact and lightweight, this handheld oscilloscope is practical for various testing tasks. Easy to operate with a user-friendly interface, this device is a versatile tool for electronic enthusiasts.
Color : #511
IncludedComponents : no
ItemName : 3 in 1 Digital Oscilloscope Transistor Tester Generator with Multimeter Meter Tester Digital Voltage Capacitor Multi Volt Ohm Automotive Capacitance Electrical Electronic Meters
ItemPackageDimensions_Height : 6 centimeters
ItemPackageDimensions_Length : 20 centimeters
ItemPackageDimensions_Width : 10 centimeters
ItemTypeKeyword : Multimeters
Manufacturer : WALFRONT
MeasurementAccuracy : 0.1mm
ModelNumber : WALFRONT2dpsmt8ygb
NumberOfItems : 1
PartNumber : WALFRONT2dpsmt8ygb
PowerSourceType : Ac/Dc
ProductDescription : 1. 3 in 1 Device: This device combines the functions of a digital oscilloscope, an electronic component tester, and a PWM signal generator. Oscilloscope mode can test the signal waveform of the circuit; Mos Test mode can test various types of transistors, identifying type, pin polarity, hFE, on voltage, capacitance, resistive value, inductance components, etc. The signal generator mode can use sine, square, pulse, triangular or oblique waves
2. Working Parameters: The oscilloscope has a real time sampling rate of 48MSa/s and a bandwidth of 10MHz, which can measure voltage signals up to 400V. Signal generator has built in 13 basic waveforms, sine wave frequency output 0-50KHz 0.1V-3.0V , vertical sensitivity of 10mV div-10V div, horizontal time base range of 50ns-20s, more waveform data can be obtained per unit time, so as to make the waveform more accurate
3. Battery and Screen: Built in 1500mAh battery, will be fully charged in 1-2 hours by using 5V 2A interface, can work for 4 hours (green light when completed, red light when charging); The digital oscilloscope and transistor tester feature a high resolution 2.8 inch screen with adjustable backlight for a better reading experience
4. Portable and Practical: The handheld oscilloscope can test different functions, support multi interface screen display, adopt key design, more convenient to operate, choose different test function mode; The compact and lightweight design provides variety and convenience for the user
5. Multiple Functions: The digital oscilloscope support computer online work, users can refresh the official firmware, complete the upgrade, especially suitable for the rapid pairing of transistors, mixed surfaces mount and no word component recognition, small batch component preliminary screening; It can automatically identify and measure a variety of transistors, including NPN and PNP transistors, diodes, double diodes, etc

Spec:
Item Type: 3 in 1 Oscilloscope
Screen: 2.8 Inch Color Screen with LED Backlight
Power Voltage: 1 x 803450 1500mAh Li Battery (built in)
Charging Specification: USB Type C
Stand Specification: Foldable Integrated Stand
Digital Oscilloscope Mode Parameters:
Real Time Sampling Rate: 48MSa/s
Analog Bandwidth: 10MHz
Input Impedance: 1MΩ
Coupling Mode: AC DC
Testing Voltage Range: 1:1 Probe: 80Vpp (+40V); 10:1 Probe: 800Vpp (+400V)
Vertical Sensitivity: 10mV/div-10V/div (x1 range)
Horizontal Time Base Range: 50ns-20s
Actuator Mode: Auto, Normal, Single
Actuator Type: Rising Edges, Falling Edges
Waveform Freeze: Yes (HOLD Function)
Automatic Measurement: Maximum, Minimum, Average, RMS, Vpp, Frequency, Period, Duty Cycle
Component Test Mode Parameters:
Category Range Description
Triode Magnification hfe, base emitter voltage Ube, lc/le, collector-emitter reverse cut-off current lceo, lces, protective diode forward voltage drop Uf
Diode Forward Voltage Drop Forward voltage drop, junction capacitance, reverse leakage current
Voltage Regulator Diode 0.01-4.5V (1-2-3 Test area) Forward pressure drop
Field Effect Tube JFET Gate capacitor Cg, drain current ld under Vgs, protecting diode forward voltage drop Uf
IGBT Drain current ld under Vgs, protecting diode forward voltage drop Uf
MIOSTET Open voltage Vt, gate capacitor Cg, drain source resistor Rds, protecting diode forward voltage drop Uf
Unidirectional Thyristor Open Voltage Gate Voltage
Bidirectional Thyristor Actuator Current
Capacitance 25pF-1000uF Capacitance Value, Loss Factor Vloss
Resistor 0.01-50MΩ Resistive Value
Inductance 10uH-1000uH Inductance Value, DC Resistive Value
Temperature Sensor Pins: GND, DQ, VDD
Temperature and Humidity Sensor Pins: VDD, DATA, GND Signal Generator Parameters:
Output Waveform: Support 13 Waveform Output
Waveform Frequency: 0-50KHz
Square Wave Duty Cycle: 0-
Waveform Amplitude: 0.1V to 3.0V

How to Use:
Open the packaging and take out the product for immediate use.

packing list:
1 x Main Unit
1 x USB Cable
3 x Test Hook Cables
1 x Ordinary Probe
2 x Crocodile Clamp/Holder Test Cables
1 x P6100 High Voltage Probe
1 x P6100 High Voltage Probe Accessory
10 x Accessories
1 x User Manual
