Product Information
Editorial Review
This extremely low profile (< 0.6 inches tall) fixed mount omni-directional antenna provides 2 dBi of gain and works on all 2.4 & 5.8 GHz Wi-Fi frequency bands worldwide. Permanently mounts via a 1/2 in. (12 mm) hole with locking internal nut. Resists vandalism with no exposed coax cable. Includes 6 ft of low-loss coax fed through center mounting post. Designed applications requiring an inconspicuous low-profile external antenna such as kiosks, vending machines, equipment panels, conference rooms, etc. Can also be vehicle mounted for buses, vans, trucks or other mobile installations. Integrated RPSMA male plug connector mates with RPSMA female jack on access points, routers, etc. Key Specifications: Frequencies: 2.4 - 5.8 GHz Impedance: 50 ohms Gain: 2 dBi Radiation Pattern: Omni Polarization: Vertical VSWR: ADGP < 1.5:1 Max Input Power: 20W Ground Plane: Integrated Coax Cable: 6 ft (2m) low-loss RG316 Connector: SMA Male Operating Temp: -30C to +75C Height: 0.6 inches/ 15 mm Diameter: 1.8 inches/ 46 mm This antenna is also available for Cellular frequencies. See ASIN B00K9G25NA https:///dp/B00K9G25NAProxicast is a USA-based manufacturer of wireless equipment.
Features
1) 0.6 inches high x 1.8 inches diameter
2) Works with any 2.4 or 5.8 GHz Wi-Fi access point or router
3) 2 dBi gain - integrated ground plane
4) No exposed cable when installed. Water-tight when mounted correctly.
5) RPSMA Male connector with 6 ft coax pigtail cable
Specification
Binding : Electronics
Brand : Proxicast
Color : Single Antenna
EAN : 0617237750532
Label : Proxicast
Manufacturer : Proxicast
PackageDimensions_Weight : 0.02 pounds
PackageDimensions : L:6.30 X W:2.10 X H:2.10
ProductGroup : PC Accessory
ProductTypeName : NETWORKING_DEVICE
Publisher : Proxicast
Studio : Proxicast
Title : Proxicast Ultra Low-Profile Wi-Fi Omni-Directional 2 dBi Screw-Mount Antenna for 2.4/5.8 GHz Systems
