BatteriesIncluded : 1
Brand : Reland Sun
BulletPoint : ISM14780P
BulletPoint1 : NPN Output Four-Way optocoupler Isolation PLC Level Voltage Conversion Board 1.8V 3.3V 5V 12V 24V Unidirectional Transmission
BulletPoint2 : Adopt brand new original optocoupler.
BulletPoint3 : The limit switching frequency is 20KHZ.
BulletPoint4 : Widely used, it can be used for signal isolation, level conversion between MCU, PLC and other signals, PNP, NPN signal to NPN signal, signal level voltage conversion and other purposes.
BulletPoint5 : NOTE: Kindly compare your original item with the photos provided for the listing to make sure that you are purchasing the correct part. we don't provide technical assistance please make sure you are familiar with the product before purchasing. apologize in advance.
CurrentRating : 5 milliamps
ExternallyAssignedProductIdentifier : 3606480632938
ExternallyAssignedProductIdentifier1 : 0739227473402
ExternallyAssignedProductIdentifier2 : 739227473402
IncludedComponents : ISM14780P
InputVoltage : 5 volts
ItemName : NPN Output Four-Way optocoupler Isolation PLC Level Voltage Conversion Board 1.8V 3.3V 5V 12V 24V Unidirectional Transmission (1.8V to 12V)
ItemPackageDimensions_Height : 10.5 centimeters
ItemPackageDimensions_Length : 5.8 centimeters
ItemPackageDimensions_Width : 6.1 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : optocouplers
Manufacturer : Reland Sun
Material : Copper
MaximumFrequency : 60 hertz
MinimumFrequency : 50 hertz
ModelNumber : ISM14780P
MountingType : 表面安装
NumberOfBoxes : 1
NumberOfItems : 5
NumberOfLithiumIonCells : 1
NumberOfPorts : 1
PartNumber : 739227473396
ProductDescription : description?
1. Adopt brand new original optocoupler.
2. The limit switching frequency is 20KHZ.
3. Widely used, it can be used for signal isolation, level conversion between MCU, PLC and other signals, PNP, NPN signal to NPN signal, signal level voltage conversion and other purposes.

Module terminal and definition:
signal input
1+: The first signal input positive
1-: The first signal input negative
2+: The second signal input positive
2-: The second signal input negative
3+: The third signal input positive
3-: The third signal input negative
4+: The fourth signal input positive
4-: The fourth signal input negative
power input
VCC: DC power supply positive (*)
GND: DC power negative
Signal output
O1: The first signal output (Output)
O2: The second signal output (Output)
O3: The third signal output (Output)
O4: The fourth signal output (Output)
(*) : The DC power supply is the same as the signal output voltage. For example, if the signal is 24V to 5V, then VCC = 5V input.

Module wiring: (The output signal is a few V, the module power supply uses a few V. The following uses "24V to 5V" as an example, the signal conversion of the remaining voltages are similar)
