Specification
Brand : PZPZP
BulletPoint1 : Two selectable differential input channels.
BulletPoint2 : On-chip active low noise PGA with selectable gain of 32, 64 and 128.
BulletPoint3 : On-chip power supply regulator for load-cell and ADC analog power supply.
BulletPoint4 : On-chip oscillator requiring no external component with optional external crystal.
BulletPoint5 : Simple digital control and serial interface: pin-driven controls, no programming needed.
Color : 5KG
ExternallyAssignedProductIdentifier : 7504354413934
ItemName : Load Cell, Digital Load Cell Weight Sensor HX711 AD Converter Breakout Module 5KG 10KG Portable Electronic Kitchen Scale,for Measure Force, Pressure(5KG)
ItemPackageDimensions_Height : 8 centimeters
ItemPackageDimensions_Length : 15 centimeters
ItemPackageDimensions_Width : 10 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : industrial-scale-and-balance-parts
Manufacturer : PZPZP
MeasurementAccuracy : 1
ModelNumber : 248279819
NumberOfBoxes : 1
NumberOfItems : 1
PartNumber : 248279819
ProductDescription : Features:
On-chip power-on-reset.
Selectable 10SPS or 80SPS output data rate.
Current consumption including on-chip analog power supply regulator: normal operation andlt; 1.5mA power down andlt; 1uA.
Operation supply voltage range: 3.3V - 5V.
Operating Temperature Range: -20 degree - +85 degree.
HX711 is Mounted on breakout board, includes headers for connection, soldering required

Parameter:
Bracket Diameter: 10cm(Tray Diameter)
Operation Voltage: 3.3V5V(recommended 5V)
Maximum Measures Force: 5kg
Appearance Height: 3.5cm(include Pillar)
AD Module: HX711(24 bit high precision A/D converter chip hx711)
Post-calibration Accuracy: Within 1g
Operation Current: andlt; 1.5mA
Connection:Red to E+
Black to E-
Green to A+
White to A-

Note:
Be sure not to directly press on the white cover to prevent damage to the sensor.

Package Including
1 * Weight Sensor
1 * HX711 24BIT Precision AD Module

Converter, Sensors, Active Components, Electronic Components & Supplies
ProductSiteLaunchDate : 2025-03-26T03:22:07.078Z
Size : HX711
UnitCount : 1
UnspscCode : 52150000
