Specification
Brand : XMSJSIY
BulletPoint1 : 【 Bidirectional DP Switch 】 DisplayPort Bi-directional switch can connect two DP signal sources to the DP display, or connect the DisplayPort signal source to switch between 2 displays. Press the 'Select' button to switch between the 2 displays. (Important note: Two displays cannot be displayed simultaneously). USB cable power supply for use
BulletPoint2 : 【 8K Ultra-HD Resolution 】 8K DP 1.4 switch support 8K@60Hz 4K@120Hz and 1080P@240Hz Resolution of. 8K standard DP1.4 data cable for visual effects, supporting HDCP and DPCP for clear graphics and high-definition audio
BulletPoint3 : 【 High Speed Data Transmission 】DisplayPort splitter provides data transmission up to 32.4Gbps, without delay, flicker, high-definition video output, vivid details, and a realistic experience. Not only can the standard DP1.4 data cable be used, but it is backward compatible with all previous DP standards. Note: The total length of input and output wires should not exceed 3 meters, otherwise the signal may be shielded
BulletPoint4 : 【 High quality performance 】8K DP switch is equipped with a frosted metal outer shell, which is anti drop and not easy to scratch; The switch "select" button is sensitive; Gold plated interface with built-in high-performance chips to ensure stable signal transmission
BulletPoint5 : 【Plug and Play】DisplayPort Bi-directional switch does not require a driver, but requires an external power supply. The DP selector box is easy to install and operate. When in use, simply press the "Select" button to replace the signal; The LED indicator light can be used to check the working status at any time. Suitable for computers, televisions, projectors, monitor
BulletPoint6 : Gross Weight：0.5Kg
BulletPoint7 : Certification：CE, FCC, RoHS
Color : Black
CompatibleDevices : Electronic Devices (e.g., Laptops, Tablets, Smartphones, Cameras, etc.)
CompatibleDevices1 : Television
CompatibleDevices2 : Laptop
CompatibleDevices3 : Monitor
CompatibleDevices4 : Personal Computer
CompatibleDevices5 : Projector
ConnectivityTechnology : USB
ConnectorGender : Female-to-Male
ConnectorType : DP
ControlMethod : application
ExternallyAssignedProductIdentifier1 : 0859777007725
ExternallyAssignedProductIdentifier2 : 859777007725
FormFactor : Desktop
FrequencyRange : 50Hz to 60Hz
IncludedComponents : 1 power cable
InputVoltage : 24 volts_of_direct_current
ItemName : XMSJSIY DisplayPort Switch 8K Bi-directional DP 1.4 Switcher 1 in 2 out / 2 in 1 out High Speed Splitter DP Switch Converter Supports 8K@30Hz 4K@120Hz for PC Monitor Laptop HDTV
ItemPackageDimensions_Height : 1.18 inches
ItemPackageDimensions_Length : 5.5 inches
ItemPackageDimensions_Width : 3.9 inches
ItemPackageQuantity : 1
ItemTypeKeyword : audio-video-selectors
Manufacturer : Yingtuyou jiaju
Material : Plastic
ModelNumber : ANI-0102POE-XT
MountingType : Wall Mount
NumberOfItems : 1
NumberOfPorts : 3
NumberOfPowerLevels : 4
OutputCurrent : 2.5 amps
OutputVoltage : 24
PartNumber : DP Sw
PowerPlugType : type_b_3pin_na_jp
PowerSourceType : AC
ProductDescription : Bi-Direction 1in 2out 2in 1out DisplayPort 1.4 Switcher 8K@30Hz 4K@120Hz High Speed 32.4Gbps 8K DP Switch 1.4 Splitter

How to use DP bidirectional 8K switch:
1: Mode 1 (Switch)
Connect the source device to the DisplayPort switch using two DP cables, and then connect one DP cable to the monitor. Press the 'Select' button to switch between the two source devices.

2: Mode 2 (Splitter)
Connect the source device to the DisplayPort switch using a DP cable, and then connect two DP cables to the monitor. Press the 'Select' button to switch between the two monitors. In this situation, both monitors cannot display simultaneously!

Specification:
●Type: DP Bi-direction Switch
●Input/Output Interface: DisplayPort
●Port: 1 Input 2 Output, 2 Input 1 Output
●Resolution: 8K@30Hz 4K@120Hz
●Power: Type-C cable
●Bidirectional use, can be used for 2 computer hosts connected to 1 monitor, or 1 computer host connected to 2 monitors

Note:
1、DP 1.4 Switch can't switch automatically, only by manually pressing the select button
2、The length of DisplayPort cable should not exceed 3 meters
3、If the resolutions of two computers or monitors are different, the final output resolution depends on the lower resolution device
ProductSiteLaunchDate : 2023-10-25T06:28:52.346Z
Size : 12x9x3cm
SpecificationMet : CE
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
UnspscCode : 52161500
WarrantyDescription : 1 Year Warranty
Wattage : 90 watts
