Specification
AgeRangeDescription : 8+
AssemblyTime : 5 hours
Brand : Stemedu
BulletPoint : Servo reversing Three-point programming Deadband programming High-speed input 3 servo modes
BulletPoint1 : High Voltage Brushless Servo: 4.8v~8.4v DC
BulletPoint2 : High Speed Brushless Servo: 0.18sec/60° at 4.8v, 0.14sec/60° at 6.0v, 0.12sec/60° at 7.4v, 0.1sec/60° at 8.4v
BulletPoint3 : High Torque Brushless Servo: 53kg.cm at 4.8v, 56kg.cm at 6.0v, 60kg.cm at 7.4v, 63kg.cm at 8.4v
BulletPoint4 : Control system of 60kg brushless servo is PWM (Pulse Width Modification), its range is from 500 to 2500μsec. The control angle is from 0 to 180° when 500-2500μsec.
BulletPoint5 : This 60KG waterproof servo suitable for 1/8 1/10 1/12 RC car buggy, truggy, crawler, off-road vehicle, robots, mechanical arms, remote control boat & giant scale aircraft etc
Color : Black
CpsiaCautionaryStatement : no_warning_applicable
EducationalObjective : Science
ExternallyAssignedProductIdentifier : 4548565270033
ExternallyAssignedProductIdentifier1 : 605482336847
ExternallyAssignedProductIdentifier2 : 0605482336847
GpsrSafetyAttestation : 1
IncludedComponents : 60KG RC Digital Servo
IndoorOutdoorUsage1 : indoor
IndoorOutdoorUsage2 : outdoor
ItemDisplayDimensions_Height : 1.5 inches
ItemDisplayDimensions_Length : 4.5 inches
ItemDisplayDimensions_Width : 4 inches
ItemDisplayWeight : 0.5 pounds
ItemName : Stemedu 180° RC Servo 60KG High Torque Steering 0.12sec/60° at 7.4V High-Speed, Brushless Digital Motor, Stainless Steel Gear, Waterproof, for DIY RC Models, Robotic Toys
ItemPackageDimensions_Height : 1.6 inches
ItemPackageDimensions_Length : 1.6 inches
ItemPackageDimensions_Width : 1 inches
ItemPackageQuantity : 1
ItemTypeKeyword : hobby-rc-vehicle-servos
Language : english
Manufacturer : Stemedu
ManufacturerMaximumAge : 1500
ManufacturerMinimumAge : 2
Material : Plastic
Material1 : Aluminum
Material2 : Steel
Material3 : Plastic
ModelName : Angle - 180 degree
ModelNumber : H60-180
NumberOfBoxes : 1
NumberOfItems : 1
NumberOfPlayers : 1
OperationMode : Automatic
PackageLevel : unit
PartNumber : H60-180
PowerSourceType : electric
ProductDescription : Specification:
Operating Voltage: 4.8 ~ 8.4 DC Volts
No-load speed: 0.18sec/60° (at 4.8V), 0.14sec/60° (at 6V), 0.12sec/60° (at 7.4V), 0.10sec/60° (at 8.4V)
Running current: 500mA-800mA (at 4.8-6V), 700mA-1200mA (at 7.4-8.4V)
Stall torque: 53 Kg-cm (at 4.8V), 56 Kg-cm (at 6V), 60 Kg-cm (at 7.4V), 63 Kg-cm (at 8.4V)
Stall current: 8000mA-9000mA (at 4.8V), 9000-10000mA (at 6V), 10000-11000mA (at 7.4V), 11000-12000mA (at 8.4V)
Motor Type: Brushless Motor
Gear Type: Stainless Steel
Case Material: Aluminum Alloy
Command signal: Pulse width modification
Pulse width range: 500～2500μsec Amplifier type: Digital controller
Working frequence: 1520μs / 333hz
Dead band: 3μsec
Control angle: 180°±3° (when 500～ 2500μsec)
Neutral position: 1500μsec Rotating direction: Counterclockwise (when 1000～ 2000μsec)

Limit Angle: 360°
Gear Type: 5 Metal
Bearing: 2BB
Horn: 25T dia: 5.95mm
Storage Temperature: -30°C~80°C
Operation Temperature: -10°C~60°C
Size: 40 x 20.5 x 39.8 mm ( 1.58 x 0.79 x 1.59 in)
Connector Wire: 300mm±5mm
Weight: 85g
Package Includes:
1 x 60KG Black All-metal Carbon Brush Motor Servo
1 x 25T servo horn arm
1 x accessories

ProductSiteLaunchDate : 2024-08-27T06:48:12.531Z
SafetyWarning : WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. The product manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
ScaleName : 1/10
Size : Medium
StreetDate : 2022-09-24T00:00:01Z
Style : Modern
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredHasProductIdentifierExemption : 1
TargetAudienceKeyword : Unisex Adult
TargetAudienceKeyword1 : Men
TargetAudienceKeyword2 : Unisex
TargetAudienceKeyword3 : Women
TargetGender : unisex
Theme : Vehicle
Theme1 : truck
Theme2 : car
ToyVehicleForm : Truck
UnitCount : 1
UnspscCode : 60140000
