Specification
Brand : QTSEGSEE
BulletPoint1 : Industrial Motors
BulletPoint2 : Nema 23 stepper motor 1.85Nm 2.8A with magnetic encoder 6.35mm shaft motor stepper motor
Color : One Color
ExternallyAssignedProductIdentifier : 9010064769776
ItemName : Nema 23 stepper motor 1.85Nm 2.8A with magnetic encoder 6.35mm shaft motor stepper motor
ItemPackageDimensions_Height : 1 centimeters
ItemPackageDimensions_Length : 3 centimeters
ItemPackageDimensions_Width : 2 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : switch-encoders
Manufacturer : QTSEGSEE
ModelName : QTSEGSEE
ModelNumber : QTSEGSEE
NumberOfItems : 1
PartNumber : QTSEGSEE
ProductDescription : Industrial Motors
This nema 23 stepper motor has a torque of 1.85Nm (256.9oz.in). The encoder is a magnetic encoder with 3 channels and 1000PPR (4000CPR) resolution. The biggest advantages of magnetic encoders are size and cost, they are widely used in small spaces and have higher cost performance.
Manufacturer Part Number: 23HS30-2804-ME1K
Number of phases: 2
Step angle: 1.8 degrees
Holding torque: 1.85Nm (256.9oz.in)
Rated current/phase: 2.8A
Phase resistance: 1.13os±10%
Inductance: 4.8mH±20% (1KHz)
Frame size: 57 x 57mm
Body length: 80mm
Shaft diameter: 6.35mm
Shaft length: 21mm
D-CUT shaft length: 15mm
Lead length: 500mm
Weight: 1.0kg
Output circuit type: Differential
Encoder type: Magnetic incremental
Encoder resolution: 1000PPR (4000CPR)
Output signal channel: 3 channels
Minimum supply voltage: 3.3V
Maximum supply voltage: 5.5V
Output current: 20mA
Output high voltage: 5V
Output low voltage: 0.2V
Maximum output frequency: 400kHZ

==========
Current/Phase: 2.8A
Holding torque: 1.85Nm (256.9oz.in)
Step angle (degrees): 1.8 degrees
Stage: 2
Model: 23HS30-2804-ME1K
Type: Mixed
Certification: ce, ROHS
Origin: Mainland China
Phase resistance: 1.13os±10%
Body length: 80mm
Shaft diameter: 6.35mm
Shaft length: 21mm
Lead length: 500mm
ProductSiteLaunchDate : 2024-10-24T03:40:41.042Z
Size : One Size
UnitCount : 1
UnspscCode : 26101200
