Specification
Brand : WnewTools
BulletPoint1 : Pixel Size: 12um
BulletPoint2 : IR Sensor Resolution: 256X192
BulletPoint3 : NETD: u226450mK@25xb0C,F#1.0
BulletPoint4 : Spectral Band: 8u301c14um
BulletPoint5 : Size: 27*18*9.8(mm)
ExternallyAssignedProductIdentifier1 : 0769902987221
ExternallyAssignedProductIdentifier2 : 769902987221
IncludedComponents : No
ItemName : P2 Thermal Imager IR Sensor Resolution 256 * 192 Mobile Phone Infrared Thermal Imager Camera Thermal Leak Diagnosis Thermal Sensor Thermometer
ItemPackageQuantity : 1
ItemTypeKeyword : thermal-imagers
Manufacturer : Wnew
ModelName : Thermal Imager
ModelNumber : ATOOL1864876
NumberOfItems : 1
NumberOfPieces : 1
PackageLevel : unit
PartNumber : ATOOL1864876
PowerSourceType : hand_powered
ProductDescription :

Feature:

IR Sensor Resolution: 256X192

Pixel Size: 12um

NETD: ≤50mK@25°C,F#1.0

Spectral Band: 8〜14um

Size: 27*18*9.8(mm)

Weight: 9g

Control Interface: USB typeC

Performance

Frame Rate: 25Hz

Operating Temperature: -10℃-55℃

Storage Temperature: -40℃-85℃

Power Consumption: 350mW

Processor: Self-developed ASIC chip

Lens

Focal Length: 3.2mm

Aperture: F1.1

FOV: 56.0°x42.2°

Focusing Mode: Athermalized fixed focus lens

Temperature Measurement

Measuring Range: -20℃-170℃

Measuring Error: ±3℃ (±3% of reading, the greater shall prevail)

Temperature Correction: Emissivity, distance, environmental temperature

Software Function:

Palettes: White/Black hot and 6 color palettes

Temperature Measurement Mode: Point/Line/Area temperature measurement

Information Sharing: Instant picture sharing

Data Analysis: Secondary temperature analyzing and processing of thermal images

Imaging Tool: Android 6.0 and above

Software Update: Online update

Package Included:

1 x Thermal Imager

1 x Manual

1 x Packing Box

Common Problem:

1.Q: Why can't the image of OPPO, VIVO, IQOO mobile phone be displayed after connecting?

A: The method is as follows: mobile phone settings option ― search bar ― input OTG ― after finding the option, set it to the on state.

2.Q: If it is an old mobile phone, how to connect the thermal imager if the interface is Micro?

A: Need to use Type-C female port to Micro male port adapter to use, and must support OTG function.

3.Q: Can the Apple version and the Android version be compatible?

A: No. These are two completely different systems, and the interface hardware is essentially different, so they cannot be used universally through adapters.
