Specification
AgeRangeDescription : adult
Brand : Yale Security
BulletPoint : US32D Stainless Steel Finish
BulletPoint1 : 630 Satin Stainless Steel Finish
BulletPoint2 : 30" - 36" (76cm - 91cm) doors
BulletPoint3 : ANSI/BHMA Certified: A156.3 Type 1, Grade 1
BulletPoint4 : Handed. (field reversible)
BulletPoint5 : 3 Hour Fire exit hardware (F)
Color : W X H
ExteriorFinish : Bronze
ExternallyAssignedProductIdentifier : 7322609122727
InstallationType : Screw-In
ItemName : Yale 7110F 3 Hour Fire Rated Surface Vertical Rod Exit Device 30"-36" Door 630
ItemPackageDimensions_Height : 1 centimeters
ItemPackageDimensions_Length : 1 centimeters
ItemPackageDimensions_Width : 1 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : commercial-access-touch-bar-devices
Manufacturer : Yale Commercial Hardware
Material : Metal
ModelName : 01020
ModelNumber : 01020
NumberOfBoxes : 1
NumberOfItems : 1
PartNumber : 7110F6303
ProductDescription :

The 7110(F) is a surface vertical rod exit device to be used on wide stile or flush doors up to 8' (fire) and 10' (panic) where two-point latching is desired.

ANSI/BHMA Certified: A156.3 Type 2, Grade 1

• Designed for wide stile and flush doors
• Handed. Specify hand (field reversible)
• Bottom deadbolt for secure latching
• Fully adjustable roller strike

• Pairs of doors
• Double egress
• Metal, wood or composite door materials

Door Opening Width:

-36 for 30" - 36" (76cm - 91cm) doors
-48 for 36" - 48" (91cm - 122cm) doors

Optional sizes can be special ordered. Consult Technical Product Support.

Door Opening Height: Standard door height 7' (213cm), with the device centerline at 39-15/16" (101cm) from floor.

Optional heights up to 8' (fire) and 10' (panic) available by using rod extensions. For fire rated openings over 8', see 7170F SVR.

Door Thickness: 1-3/4" (44mm) standard. Optional door thicknesses available to 4-1/2"; specify door thickness when ordering.

Minimum Stile Width: 4-1/2" (114mm)

Projection: 3-1/4" (83mm) active, 2-3/4" (70mm) dogged

Latchbolt: Top: 3/4" (19mm) throw, pullman-type with automatic deadlatching

Bottom: 5/8" (16mm) throw deadbolt, held retracted during door swing

Vertical Rods: 1/2" O.D. tubular brass, bronze or stainless steel with rod guides

Strike: Top: Roller type 791. Bottom: Flush mounted 790. 794 floor strike optional (threshold openings).

Fasteners: Machine screws and wood door fasteners standard for panic hardware. Sex nuts and bolts supplied standard for fire exit hardware.

Trims: 620F series escutcheon trim, 630F series pull/thumbpiece trim, 680F series offset pull trim, 540F series rose trim.

Dogging: Hex key dogging supplied standard on panic devices

Warranty: 5-year limited

ProductSiteLaunchDate : 2016-09-23T20:34:33.090Z
Size : 8x7mm (0.31"x0.28")
SpecificationMet : ANSI
UnitCount : 1
UnspscCode : 31160000
