Product Information
Editorial Review
Add External six Ports and Internal 1 Port USB 3.0 SuperSpeed 5Gbps in Low Profile PCIe Host Adapter to support all kind of USB 3.0, USB 2.0, USB 1.1 Devices. Specification * Connector: - 7 x USB 3.0 Type-A female (6x external + 1x internal) - 1 x 15-pin SATA power connector (optional connection) * Chipset: Renesas uPD720201 + uPD720210 (Hub) * Software: - No driver installation is required on Windows 10, Win8, Server 2012, Linux kernel 2.6.31 and later OS. The OS buit-in USB drivers support UASP. - The Renesas drivers are available for 32/64 bit Windows Windows 7/Vista/XP, and 64bit Server 2008 R2 * Data transfer rate: - USB 3.0 up to 5 Gbps * USB 3.0 PCI Express 2.0 x1 Lane Host Adapter * Supports PCIe 1.0 and PCIe 2.0 motherboard * Compliant with PCI Express Specification 2.0 * Compliant with Universal Serial Bus 3.0 Specification Rev. 1.0 * Compliant with Intel eXtensible Host Controller Interface (xHCI) Specification 1.0 * Support USB Attached SCSI Protocol (UASP). * Support USB3.0, USB2.0 and USB1.1 devices * Provides 5V/1A USB bus power to USB devices from Motherboard PCIe slot directly, or from PC power supply if on board 15Pin SATA power connector connected * Low Profile PCIe Form Factor board * Include both Low Profile and Regular Size PCIe brackets * Fully RoHS compliant. * Made in Taiwan Package Contents * Ableconn USB 3.0 7-Port PCIe Host Adapter Card * One (1) low profile PCIe bracket * Quick Installation Guide
Features
1) Seven USB 3.0 Type-A connectors. Up to 5Gbps data transfer speed.
2) PCIe x1 lane Low Profile board. Include both Low Profile and Regular Size PCIe brackets.
3) Instead of taking 5V power directly from power supply, our design includes power switching regulator circuit that automatically converts 12V from PCIe bus or from 15-Pin SATA power to ensure sufficient 5V/1A bus power on each USB port.
4) No driver installation is required on Windows 10, Win8, Server 2012, Linux kernel 2.6.31 and later OS. The OS buit-in USB drivers support UASP.
5) Built with Renesas NEC uPD720201. High quality. Fully RoHS compliant. Made in Taiwan.
Specification
Binding : Electronics
Brand : Ableconn
Label : Ableconn
Manufacturer : Ableconn
Model : PEX-UB127
PackageDimensions_Weight : 0.30 pounds
PackageDimensions : L:6.90 X W:5.60 X H:1.30
ProductGroup : PC Accessory
ProductTypeName : COMPUTER_COMPONENT
Publisher : Ableconn
Studio : Ableconn
Title : Ableconn PEX-UB127 7-Port USB 3.0 6x External + 1x Internal PCI Express (PCIe) Low Profile Host Adapter Card - Renesas NEC UPD720201 chipset
