Specification
Brand : Mavaol
BulletPoint : Current Sense
BulletPoint1 : [EASY INSTALLATION] 35mm standard DIN rail installation, compliant with DIN EN50022 for quick setup.
BulletPoint2 : [ACCURATE ENERGY MONITORING] Ten pole width with a seven-digit LCD display for precise energy measuring up to 999999.1 kWh.
BulletPoint3 : [PULSE OUTPUT] Features polarity and nonpolarity pulse output ports for energy impulse signals, meeting IEC 62053-31 and DIN 43864 standards.
BulletPoint4 : [VISUAL INDICATION] 5 LED indicators for power supply status, energy impulse signals, and data communication for easy monitoring.
BulletPoint5 : [VERSATILE USAGE] Suitable for single-direction three-phase four-wire active energy consumption measurement, complying with IEC 62053-21.
Color : One Color
ExternallyAssignedProductIdentifier : 6430498729505
IncludedComponents : No
ItemName : Digital DIN Rail Electric Meter for Energy Measurement 3 Phase 4 Wire 7P (5(30) A)
ItemPackageDimensions_Height : 7 centimeters
ItemPackageDimensions_Length : 13 centimeters
ItemPackageDimensions_Width : 11 centimeters
ItemPackageQuantity : 1
ItemTypeKeyword : voltage-testers
Manufacturer : Mavaol
Material : Metal
MeasurementAccuracy : 0.1mm
ModelName : HDNMCNK
ModelNumber : Mavaoliyu4canzom-01
NumberOfItems : 1
PartNumber : Mavaoliyu4canzom-01
ProductDescription : [EASY INSTALLATION] 35mm standard DIN rail installation, compliant with DIN EN50022 for quick setup.
[ACCURATE ENERGY MONITORING] Ten pole width with a seven-digit LCD display for precise energy measuring up to 999999.1 kWh.
[PULSE OUTPUT] Features polarity and nonpolarity pulse output ports for energy impulse signals, meeting IEC 62053-31 and DIN 43864 standards.
[VISUAL INDICATION] 5 LED indicators for power supply status, energy impulse signals, and data communication for easy monitoring.
[VERSATILE USAGE] Suitable for single-direction three-phase four-wire active energy consumption measurement, complying with IEC 62053-21.

Spec:
Features:
35mm standard DIN rail installation , complying with standard DIN EN50022.
Ten pole width (Modulus 12.5mm), complying with standard JB/T7121-1993.
Type S wiring (Type U).
Seven digits display LCD, 6+1 digits display (999999.1 kWh) .
There are a polarity port of pulse output passive closed and a nonpolarity port of pulse output passive distant . Complying with standard IEC 62053-31 and DIN 43864.
5 LED instructions respectively every power supply state, signal of closed energy impulse and distant energy impulse and data communication state.
Automatic detection the direction of the flow of load current. And Instructions on individual LCD
Single direction three components measure three phase four wire active energy consumption. It is nothing with direction of the flow of load current. Complying with standard IEC 62053-21.
Standard configuration short terminals cover, may select extension terminals cover, in order to protect to use safety.

Specifications:
Model: XTM1250SA-U

Accuracy: Class 1
Voltage: 3x220V/380V
Current: 5(30)A,15(60)A, 20(80)A,10(40)A, 30(100)A (Optional)
Insulation performance: AC voltage 4kv for 1 minute,1.2/50us waveform impulse voltage 6kv
Size: as the picture
Weight: 498g

Package
ProductSiteLaunchDate : 2025-05-13T12:52:02.052Z
Size : 5(30)A
UnitCount : 1
