Specification
Brand : HROMIGRY
BulletPoint : For proper performance the wedge-bolt anchor must be installed with a wedge-bit (see model No. 372152 thru 372174 series). The wedge-bit has a special matched tolerance range designed to provide optimum performance for the anchor. Packaged in a vinyl pouch
BulletPoint1 : Anchor Bolts Specifications - Diameter - 1/2", Length - 4-1/4", Qty - 25 pieces, Minimum Embedment - 2-1/4", Thread Length - 2-7/16", Pull Out Load - 5732 lbf
BulletPoint2 : Heavy Duty Material - Our cement anchors are made from carbon steel, finished with zinc to prevent rust for long and durable using
BulletPoint3 : Ideal Applications - Concrete anchor bolts work well for any mounting and structural anchorage purpose in any condition, suitable for applications in solid concrete and cement, Do not use in block or brick base material
BulletPoint4 : Multi-Purpose - Wedge anchor bolts for concrete are designed for both indoor and outdoor use. Must be inserted for minimum embedment depth to obtain minimum holding values, and comes assembled with nut & washer for your convenience
BulletPoint5 : Easy to Use - Just drill a hole as big as the diameter of the anchor in concrete (larger holes may cause the bolt to spin when tightening) , remove debris and dust from the hole, hammer the concrete wedge anchors into the hole, then tighten the nut with a wrench to complete the installation
BulletPoint6 : To install a wedge anchor simply drill a hole that is the same size diameter as the anchor and place it into the hole. After placing the material being held to the concrete on the exposed portion, place the washer and thread the fastener onto the anchor. As the nut is tightened against the washer, it will begin pulling the anchor up. This will result in the wedge skirt catching the concrete and expanding and digging into the concrete as the anchor is pulled.
Color : Silver
CustomerPackageType : Standard Packaging
DriveSystem : Phillips
ExteriorFinish : Zinc
ExternallyAssignedProductIdentifier : 3476060018908
ExternallyAssignedProductIdentifier1 : 044315538612
ExternallyAssignedProductIdentifier2 : 0044315538612
ExternallyAssignedProductIdentifier3 : 00044315538612
ExternallyAssignedProductIdentifier4 : 0044315753213
ExternallyAssignedProductIdentifier5 : 00044315753213
GpsrSafetyAttestation : 1
GradeRating : Premium
IncludedComponents : 30 x Notched Wedge
ItemName : HROMIGRY 1/2" x 4-1/4" Concrete Anchors (25 Pack) 1/2 inch Wedge Anchors Bolts Zinc Plated
ItemPackageDimensions_Height : 35.4076 centimeters
ItemPackageDimensions_Length : 10.9982 centimeters
ItemPackageDimensions_Width : 23.0124 centimeters
ItemPackageQuantity : 1
ItemShape : Block,wedge
ItemTypeKeyword : wedge-anchors
Manufacturer : HROMIGRY
ManufacturerGrade : Heavy Duty
Material : Carbon Steel
Material1 : steel
Material2 : zinc plated
MaximumShearStrength : 6.5 ksi
MeasurementSystem : Imperial
MetalType : Stainless Steel
MetalType1 : Zinc
MetalType2 : Alloy Steel
ModelName : Edma
ModelNumber : 189055
NumberOfBoxes : 1
NumberOfItems : 1
NumberOfPieces : 25
PackageLevel : unit
PartNumber : MGWA12X414P25Z
PowerSourceType : /
ProductDescription :

Hromigry Wedge Anchor Bolts, Heavy Duty Anchors for Concrete, Anchors Bolts for Indoor and Outdoor Applications

Our wedge anchor bolts for concrete are available in diameters of 3/8", 1/2", 5/8", and are available in zinc plated carbon steel and stainless steel to make the through bolt resistant to rust.
Wedge anchors can be used in solid concrete applications, and suited for fastening purposes such as- structural anchorage, storage racking anchorage, metal doors and window frames, wall mounting, plumbing systems, electrical equipment, machinery and hand rails installation, etc.

Package include 25 pieces wedge expansion anchors, each with one nut and one washer.

Installation Instructions
1. Using the hammer drill to drill a hole in the concrete, which is as big as the diameter of the wedge anchor.
2. Clean out all the dust and debris of the hole.
3. Hammer the anchor into the drilled hole to the desired depth.
4. Tighten the nut with a torque wrench to ensure the bottom portion wedge is expanded in order to lock the anchor in place firmly.

Notes Please do not use in block or brick base material, only suitable for cement, solid concrete and grout-filled concrete masonry.
ProductSiteLaunchDate : 2023-08-10T06:05:27.582Z
Size : 1/2"x4-1/4"
SpecificUsesForProduct : Residential
SupplierDeclaredDgHzRegulation : not_applicable
SupplierDeclaredDgHzRegulation1 : not_applicable
SupplierDeclaredDgHzRegulation2 : not_applicable
SupplierDeclaredDgHzRegulation3 : not_applicable
SupplierDeclaredDgHzRegulation4 : not_applicable
SupplierDeclaredDgHzRegulation5 : not_applicable
SurfaceRecommendation : Concrete, Masonry, Stone
UnitCount : 25
UnspscCode : 31161500
